KIOXIA CM7-R (2.5") - 15.36TB Read Intensive 1 DWPD PCIe 5.0 SSD
Transform your data center with the KIOXIA CM7-R Series 15.36TB SSD, a high-capacity enterprise NVMe SSD for advanced storage solutions. Driven by PCIe 5.0 and NVMe 2.0 with 112-layer BiCS FLASH TLC, this 2.5" U.3 SSD achieves up to 14,000 MB/s sequential read and 7,000 MB/s sequential write speeds, with 2,400K IOPS random read performance. Offering 1 DWPD endurance and Sanitize Instant Erase (SIE) protection, it enhances business intelligence, online transaction processing, and software-defined storage and virtualisation. 15mm thickness form factor supports high availability for continuous enterprise operations.
Product Specification for KIOXIA CM7-R (2.5") - 15.36TB Read Intensive 1 DWPD PCIe 5.0 SSD
Performance in Single Port (1x4) Mode (Up To)
| Sustained 128 KiB Sequential Read | 14,000 MB/s |
| Sustained 128 KiB Sequential Write | 7,000 MB/s |
| Sustained 4 KiB Random Read | 2,400K IOPS |
| Sustained 4 KiB Random Write | 300K IOPS |
Power Requirements
| Supply Voltage | 12 V ± 10 %, 3.3 V ± 15 % |
| Power Consumption (Active) | 25 W typ. |
| Power Consumption (Ready) | 5.5 W typ. |
Reliability
| MTTF | 2,500,000 hours |
| Warranty | 5 years |
| DWPD | 1 |
Dimensions
| Thickness | 15.0 mm +0 / -0.5 mm |
| Width | 69.85 mm ± 0.25 mm |
| Length | 100.45 mm Max |
| Weight | 130 g Max |
Environmental
| Temperature (Operating) | 0 °C to 73 °C |
| Temperature (Non-operating) | -40 °C to 85 °C |
| Humidity (Operating) | 5 % to 95 % R.H. |
| Vibration (Operating) | 21.27 m/s² ( 2.17 Grms ) ( 5 to 800 Hz ) |
| Shock (Operating) | 9.8 km/s² ( 1,000 G ) ( 0.5 ms ) |
तेज़, कुशल और विश्वसनीय प्रदर्शन.
अल्ट्रा-फास्ट PCIe® 5.0 स्पीड
तेज़ डेटा स्थानांतरण और सिस्टम प्रतिक्रिया का आनंद लें।
कम शक्ति, उच्च दक्षता
कम ऊर्जा उपयोग के साथ मजबूत प्रदर्शन प्रदान करता है।
24x7 एंटरप्राइज़ विश्वसनीयता
निरंतर, मांग वाले कार्यभार वाले वातावरण का सामना करने के लिए निर्मित।
